Ductable Air-conditioners

Get a Price/Quote

MOQ : 1 Unit

Ductable Air-conditioners Specification

Sensible control
Yes

Power Consumption
6.2 kW

Refrigerant
R410A

Compressor
Scroll

Running Current
10.8A

Place of Origin
India

Condition
New

Dimension (L*W*H)
1800mm x 550mm x 490mm

Outdoor Fan Input
125 W

Power Mode
AC

Power Supply
Three Phase

Mounting
Ceiling Suspended/Duct Mount

Temperature Control
Digital Thermostat

Type Of Compressor
Hermetically Sealed

Indoor Fan Input
365 W

Air Flow Capacity
2200 CFM

Filtration Grade
High

Cooling Capacity
66000 BTU/hr

Type
Ductable Air-conditioner

Cooling/Heating
Cooling Only

Capacity
5.5 Ton

Power Source
Electric

Voltage
380-415V

Color
White & Blue

Weight (kg)
135 kg

Working Temperature
-10C to 54C

Fan Speed
2

Noise Level
Low

Energy Efficiency Rating
3 Star

Remote Operated
Yes

Static Pressure
30 mm WG

Drain Pipe Connection
25 mm OD

Controller Type
Wired Remote with Optional Wireless

Piping Connection
Flare Type

Protection Class
IP21

Maintenance Access
Side/Bottom Openable Panel

Application
Commercial & Industrial Spaces

Installation Service
Yes, available on request

Fan Type
Centrifugal Double Inlet

Cabinet Material
Pre-coated Galvanized Steel Sheet

Display Type
LED/LCD Display Panel

Heat Exchanger Material
Copper Tube & Aluminium Fins

Operating Sound Level
56 dB(A)

Suggested Area Coverage
Up to 120 Sq. Mt.

Frequency
50 Hz

Ductable Air-conditioners Trade Information

Minimum Order Quantity
1 Unit

Supply Ability
2 Units Per Month

Delivery Time
7 Days

About Ductable Air-conditioners

Carrier 5.5TR Ductable AC: powerful and efficient - 5.5 Ton capacity for large spaces - Energy-efficient with inverter tech - Hidden ducts, customizable zones - Ideal for big homes, offices, or commercial spaces I want to know more about this model..

Durable and Efficient Cooling

Constructed with a pre-coated galvanized steel sheet, this ductable air-conditioner is tailored for prolonged operation in demanding commercial and industrial settings. The high-efficiency copper tube and aluminium fin heat exchanger ensure effective heat transfer, while the scroll compressor guarantees low power consumption and steady performance. With a high airflow of 2200 CFM and 3-star energy rating, this unit provides both robust cooling and energy savings.

User-Friendly Control and Installation

The system features a wired remote controller with an option for wireless operation, complemented by an intuitive LED/LCD display panel. Maintenance is simplified by openable side or bottom panels, and a 25 mm OD drain pipe connection ensures trouble-free condensate removal. Designed for ceiling suspended or duct mounting, installation services are available upon request to support seamless integration.

Designed for Versatile Applications

Covering up to 120 square meters, this AC is ideal for a variety of commercial and industrial spaces. Its high-grade filtration, low operating noise level (56 dB(A)), and digital thermostat offer dependable comfort. With a rugged enclosure, IP21 protection, and the ability to perform in temperatures from -10C to 54C, it stands up to diverse environmental demands.

FAQ's of Ductable Air-conditioners:

Q: How is the ductable air-conditioner installed in commercial and industrial spaces?

A: The unit is designed for ceiling-suspended or duct mounting installation. Professional installation service is available on request to ensure optimal setup, including correct connection of the flare-type piping, power supply (380-415V, three-phase), and 25 mm OD drain pipe.

Q: What are the main benefits of choosing this ductable air-conditioner for large spaces?

A: It offers high cooling capacity (5.5 tons/66,000 BTU/hr), covers up to 120 sq. meters, and features high airflow of 2200 CFM, making it ideal for larger commercial and industrial spaces. The robust build, energy efficiency, and advanced filtration ensure reliable, long-lasting comfort.

Q: When should regular maintenance be performed, and how accessible are the internal components?

A: Routine maintenance, such as filter cleaning and inspection of refrigerant lines, should be undertaken according to the manufacturer's guidelines. The side and bottom openable panels provide convenient access to internal components, facilitating easier servicing and upkeep.

Q: What control options and user interfaces are provided with this air-conditioner?

A: The system comes with a wired remote controller and supports optional wireless remote operation. It also features an intuitive LED/LCD display panel and a digital thermostat for precise temperature management.

Q: Where is this ductable air-conditioner most effectively used?

A: Designed for commercial and industrial environments, it excels in offices, factories, warehouses, retail stores, and institutional facilities, particularly where centralized, low-noise, and efficient cooling is required over a large area.

Q: What is the process for ordering and receiving installation support in India?

A: Customers in India can contact the dealer, distributor, supplier, or service provider for purchase and request expert installation. The product is new, comes with support, and installation is provided upon request to ensure compliance with specifications and safe operation.

Q: Which energy-saving and safety features does this air-conditioner include?

A: It holds a 3-star energy efficiency rating, uses an environmentally friendly R410A refrigerant, employs a hermetically sealed scroll compressor, and provides IP21 protection-safeguarding against condensation and foreign particles while supporting low running noise and reliable operation.
